10.3 Technical data for Solido SMART technology capsule
Outer dimensions of technology
capsule:
D = 340 mm, H = 252 mm
(High capsule: H = 352 mm)
Material:
HD-PE
Approval:
UN / 1H2 / X 38 / S
Protection class:
IPX6
Relative humidity:
max. 95% rH (condensing) permitted
Sound level:
max. 36 dB(A) at a height of 1.50 m directly above the
cover of a small wastewater treatment plant installed in
the ground (with XP-60)
Solenoid valves:
1 x 3/2-way solenoid valves, DN 13, 1/2” female
thread, IP65
Installed compressor:
HIBLOW membrane compressor
models
XP-80
Operating pressure (mbar)
147
Applicable pressure range (mbar)
60-270
Air feed rate at operating pressure
(l/min)
80
Max. apparent output of technology
capsule (S) (VA)
205
Weight (kg)
4.3
Dimensions (mm x mm x mm)
208 x 132 x 186
Protection class
IP45
In the higher capsule:
HIBLOW membrane compressor
models
HP-120
HP-200
Operating pressure (mbar)
177
200
Applicable pressure range (mbar)
30 to 300
30 to 300
Air feed rate at operating pressure
(l/min)
120
200
Max. apparent output of technology
capsule (S) (VA)
285
510
Weight (kg)
8.5
9.0
Dimensions (mm x mm x mm)
256 x 200 x 222
256 x 200 x 222
Protection class
IP45
IP45
For any other information, please see the relevant supplied documents: HIBLOW Instruction
Manual (DOKK5107 070313 TD HIBLOW HP compressor)
