7. Installation and start-up
Premier Tech 31 / 64 Solido SMART
DOKK5110E 15.04.2020
7. Installation and start-up
7.1 Checking the system components for completeness
Before the installation, check that the components are complete and in flawless condition:
Contents of the box for plants with lifter
Item
Quantity
Description
1
1 pc
Technology capsule
2
1 pc
Control cable, grey, with connection plug (15 m or 30 m); pre-
assembled
3
1 pc
Compressed air outlet for tube diffuser (BEL), DN13 and/or DN16,
white; pre-assembled
4
1 pc
Compressed air outlet for clearwater lifter (KWH), DN10, blue, pre-
assembled
5
1 pc
Overfill Alarm (Float switchSWS); pre-assembled
6
2 pc
Hose clamps
7
1 pc
Control unit
1 pc
Technical Documentation
1 pc
Approval
1
2
5
6
3
4
7
