7. Installation and start-up
Premier Tech 32 / 64 Solido SMART
DOKK5110E 15.04.2020
Attached in the container:
Loose:
In the accessory pack:
Attached in the container:
Loose:
Item
Quantity
Description
8
1 pc
Air inlet support with 3 m hose, DN25
In the accessory pack:
9
1 pc
Upper piece of the sludge removal pipe, DN160
10
1 pc
Cover for sludge removal pipe, DN160
11
1 pc
Shaft assembly set
12
1 pc
Air vent for air inlet support
13
1 pc
tube diffuser with hose, DN13 and/or DN16
(tank M2: additional tube diffuser, T-piece, stop cock)
1 pc
Optional, without a figure: DN16 nozzle for tube diffuser (from
compressor HP-120 onwards)
Important note:
The diagram showing the scope of delivery and the following installation steps
apply to the standard version single-container plant.
Please note information for plants with pumped outlet in separate manual
DOKK7314E, which is included in the delivery and part of warranty conditions.
