8. S40 control unit and available settings
Premier Tech 40 / 64 Solido SMART
DOKK5110E 15.04.2020
The following terms and abbreviations are used on the control unit user interface:
Aeration:
The aeration process that occurs during the cycle
Pause:
Break between the intermittent aeration intervals
DENI phase:
Break between the intermittent aeration intervals
Sedimentation
phase:
90-minute sedimentation phase at the end of a cycle
clearwater
discharge:
Clearwater discharge, either continuous (cont., default value) or
intermittent (see chapter 8.6.3)
Compressor:
The compressor in the capsule as a unit
BEL:
Aeration resp. tube diffuser
KWH:
Clearwater lifter
KWP:
Clearwater pump (optional instead of the clearwater lifter)
DOP:
Dosing pump (optional)
SSP:
Sludge pump (optional)
Start125%:
The aeration time is increased to 125% of the set value.
The duration of the start-up phase can be set.
The start-up phase can be activated optionally.
8.2 Navigation in the control menu
You can use the three arrow buttons on the control unit to navigate as follows in the control
menu:
Navigate up or down in the menu list to activate a menu item (an
active menu item is highlighted in black)
Press a menu item to go to a lower menu level or to start entering or
changing a setting.
When you reach the last item in a list, pressing the down button again
returns you to the higher menu level.
8.3 Installation
The housing is mounted to the wall using two screws and the two fastening brackets included
in the scope of delivery. The corresponding spacers can be glued to the rear side of the
housing in the lower section.
Note:
When installed outdoors, the unit should not be positioned in direct sunlight or
where it will receive direct rainfall. However, installation in a covered outdoor area
(e.g. under a carport) is permitted.
