Assembling the Solido SMART
®
wastewater treatment technology
Please observe the following safety instructions and assembly steps:
1. Determine the location for the control unit
Note:
The control unit should not be positioned in direct rain or sun,
and it should be located between 10 m and max. 25 m from the treatment
tank (standard cable length: 15 m; on-site up to max. 30 m permitted).
2. Lay the cable
Caution:
Never disassemble the cable plug.
Protect the plug from moisture.
Pull the control cable through the cable conduit (DN 50/DN100).
Install the sealing to the building in such a way that it is possible to change the cable at a
later point.
3. Connect the hoses
Attach the pre-fitted hose on the lifter and the supply air hose to the Solido SMART
capsule connections.
4. Install the Solido SMART capsule
Set the Solido SMART capsule on the lifter in the container.
5. Fix the cable in place
Place the grey control cable into the cable bundle holder.
6. Check the complete installation
Check the plant for pipeline gradients, aeration and deaeration, and accessibility.
7. Perform start-up
Set up the plant, perform a test run, and brief the operator (prepare the protocol).
Please note information for plants with pumped outlet in separate manual DOKK7314E,
which is included in the delivery and part of warranty conditions.
