4.6 Main Output Bus
Subgroup Meters Displays the Level of the Subgroups.
In the upper-right corner of the StudioLive are the Subgroup meters, which display
the levels of the subgroup outputs.
4.6 Main Output Bus
Main Select Button Enables Fat Channel Viewing.
As previously described in Section 4.1.1, the Select button routes its channel through
the Fat Channel, allowing you to add dynamics processing, EQ, panning, etc.
Main Fader Controls the Level of the Main Output.
The fader controls the overall level of the main stereo and mono outputs.
The white area above the fader can be used as a scribble strip Use only
oil pencils. Other types of pens or pencils cannot be wiped o.
To clean the scribble strip, use a lightly damp cloth to remove the writing Spit works
pretty well, too.
Main Bus Meters Displays the Level of the Main Output.
In the upper right corner of the StudioLive are the Main meters, which display the
output levels of the main stereo bus.
