APSRS_RevC_9/17
5
Detailed Descripons: Wire Harness Colors and Funcons
Input / Output Connector (22-pin connector) (Cont.) See page 28 for the full system diagram.
These wires are listed in order of their placement in the harness connector.
18. BLACK/WHITE – Horn Output (-)
The BLACK/WHITE wire connects to the vehicle's horn wire and supplies Ground (-) when acvated from the system.
Vericaon: The vehicle horn wire registers Ground (-) when the horn is acvated.
17. LIGHT BLUE/GREEN – Ch. 5 Aux. Output (-) (NOC 7)
The LIGHT BLUE/GREEN wire supplies Ground (-) when acvated from the remote control.
Note: This wire is programmable. Refer to NOC Programming on page 16.
16. RED/BLACK – 2nd Unlock Output (-) (NOC 12)
At its default seng, the RED/BLACK wire supplies a Ground (-) pulse when the Unlock buon is pressed 2x within 10
seconds. This requires Feature Bank 2, Feature 10, to be programed ON.
Addional Parts may be required.
Note: This wire is programmable. Refer to NOC Programming on page 16
13. BLACK/BLUE – Factory Disarm Output (-) (NOC 5)
The BLACK/BLUE wire supplies a Ground (-) pulse when the system is disarmed and when remote start is acvated.
Vericaon: In most vehicles the vehicle factory disarm wire registers Ground (-) if the driver door key cylinder is turned
to the unlock posion.
Note: This wire is programmable. Refer to NOC Programming on page 16.
19. GREEN/LIGHT BLUE – Ch. 4 Aux. Output (-) (NOC 8)
The GREEN/LIGHT BLUE wire supplies Ground (-) when acvated from the remote control.
Note: This wire is programmable. Refer to NOC Programming on page 16.
15. BLACK/LIGHT GREEN – Factory Arm Output (-) (NOC 6)
At its default seng, the BLACK/LIGHT GREEN wire supplies a Ground (-) pulse when the system is armed and when the
vehicle has been successfully started using remote start. It is typically used to re-lock vehicle doors aer remote start if
necessary.
Note: This wire is programmable. Refer to NOC Programming on page 16.
11. BLACK/RED – Pulse Aer Shutdown Output (-) (NOC 4)
At its default seng, the BLACK/RED wire supplies a Ground (-) pulse when the remote start system is shut down. It
is typically used to re-lock vehicle doors aer remote start shutdown, or pulse the vehicle's door trigger to turn o
accessories aer vehicle shutdown.
Note: This wire is programmable. Refer to NOC Programming on page 16.
10. ORANGE/BLACK – Parking Brake Input (-)
The ORANGE/BLACK wire connects to the vehicle’s parking brake wire to supply parking brake status for remote start.
Vericaon: The vehicle parking brake wire registers Ground (-) once the parking brake is engaged.
Note: This connecon is only applicable to vehicles with manual transmission, or if the Turbo Timer seng is acve
(System Programming: Bank 3, Features 10 & 16 on page 12)
12. DARK BLUE/BLACK -- External Start Input (-)
The DARK BLUE wire connects to a device or switch that, when triggered, supplies a Ground (-) output. If the vehicle
ignion is o, this input will acvate the remote start funcon.
14. BROWN/BLACK – Brake Input (+)
The BROWN/BLACK wire connects to the vehicle's brake wire to supply brake status for remote start.
Vericaon: The vehicle brake wire registers 12-Volts (+) when the brake is acvated.
