Detailed Descripons: Wire Harness Colors and Funcons
Input / Output Connector (22-pin connector) (Cont.) See page 28 for the full system diagram.
These wires are listed in order of their placement in the harness connector.
21. DARK BLUE – Trunk Release Output (-) (NOC 9)
At its default seng, the DARK BLUE wire connects to the vehicle trunk release wire or relay and supplies Ground (-)
when acvated from the remote control.
Vericaon: The vehicle trunk release wire registers 12-Volt (+) or Ground (-) when the trunk release buon is acvated.
Note: This wire can be programmed to perform the Parking Lights Output funcon by changing its opons. Refer to
Bank 2, Feature 14 on page 9 and NOC Programming on page 16.
20. RED – Door Lock (-) (NOC 10)
The RED wire supplies Ground (-) when the Lock funcon is acvated from the remote control or system.
Vericaon: The vehicle lock wire registers 12-Volts (+) or Ground (-) when the Lock buon is acvated. Addional parts
may be required. See Page 24 for common door lock wire diagrams.
Note: This wire is programmable. Refer to NOC Programming on page 16.
20. GREEN – Door Unlock (-) (NOC 11)
The GREEN wire supplies Ground (-) when the Unlock funcon is acvated from the remote control or system.
Vericaon: The vehicle lock wire registers 12-Volt (+) or Ground (-) when the Unlock buon is acvated. Addional parts
may be required. See Page 24 for common door lock wire diagrams.
Note: This wire is programmable. Refer to NOC Programming on page 16.
