46
Chapter 2 Loading Media And Ribbon
4. Thread the end of the ribbon under the rear ribbon guide roller, then
between the platen and the printhead.
You can also refer to the arrows on the printer frame or to the label inside
the media cover for media loading instructions.
Media
Printhead
Rear Ribbon
Guide Roller
