ProfiHub B5+ / B5+RD User Manual
_______________________________________________
Version 2.0 – July 2014 Page 14 / 56
ProfiHub-B5-Plus-Manual-EN.docx © PROCENTEC 2014 - Copyright - all rights reserved
1.9 Comparison table
ProfiHub A5 ProfiHub B5 ProfiHub B5+ / B5+RD
Area IP 65 IP 20 IP 20
Redundant power
supply
No No Yes
Temperature range -20 to +60˚ Celcius -20 to +60˚ Celcius -25 to +70˚ Celcius
Housing Plastic Metal Metal
Mounting Corner screws DIN-rail DIN-rail
Weight 800 g 650 g 650 g
Dimensions 213 x 210 x 95 mm 167 x 111 x 32 mm 167 x 111 x 32 mm
PROFIBUS connectors Screw terminals (inside)
Glands (outside)
Screw terminals and
DB9 connectors
Screw terminals and DB9
connectors
Alternative connectors Glands can be replaced
by M12 connectors
No No
Termination LEDs No Yes Yes
Ground rail Optional Yes Yes
Redundant channel No No Yes
Diagnostics Device None None Yes, in B5+RD
Offshore approvals None None Yes
UL approvals None None Yes
