3.2.4 Baudrate Status
Input Identifier byte: 0x11
The next input byte is to indicate the baudrate lock status.
Dec Meaning
1
No baudrate detected
2
9.6 Kbit
3
19.2 Kbit
4
45.45 Kbit
5
93.75 Kbit
6
187.5 Kbit
7
500 Kbit
8
1.5 Mbit
9
3 Mbit
10
6 Mbit
11
12 Mbit
3.2.5 Relay Status
Input Identifier byte: 0x12
The next input byte is to indicate the alarm relay status.
Hex Meaning
00
Relay is off
01
Relay is on
3.2.6 Power Status
Input Identifier byte: 0x13
The next input byte is to indicate the status of the power inputs.
Nibble 1 (bit 0..3) Meaning
0
Power 1 is active
1
Power 2 is active
Nibble 2 (bit 4..7)
4
Pending Alarm: Power 1 not active
5
Pending Alarm: Power 2 not active
Examples: 0x03: Power 1 and 2 are active
0x21: Power 1 is active, pending alarm: Power 2 not active
0x32: Power 2 is active, pending alarm: Power 1 and 2 not active (Relay
should be reset in this case)
