4 Technical Data ProfiHub B5+ / B5+RD
Technical Data ProfiHub B5+ and B5+RD
Dimensions and weight
Dimensions L x W x H (mm) with screws
Weight
167 x 111 x 32 mm
Approximately 650 g
Ambient conditions
Operating temperature
Isolation class
-25 to +70
o
Celsius
-13 to +158
o
Fahrenheit
IP 20 (DIN 40 050)
Protocol specifications
Supported Protocols
Transmission speed
Transmission speed detection
Transmission speed switch
Transmission speed detection time
Data delay time
Delay time jitter
DP-V0, DP- V1, DP-V2, FDL, MPI, FMS, PROFIsafe,
PROFIdrive and any other FDL based protocol.
9.6 kbps to 12 Mbps (including 45.45 kbps)
Auto detect (default) or selectable with rotary switch
For position 1..D on B5+RD: Diagnostics Device ON
0 = Normal repeating (Auto detect, diag off) (default)
1 = 9.6 kbps
2 = 19.2 kbps
3 = 45.45 kbps
4 = 93.75 kbps
5 = 187.5 kbps
6 = 500 kbps
7 = 1500 kbps
8 = 3000 kbps
9 = 6000 kbps
A = 12000 kbps
B = Robust repeating (auto baudrate detect)
C = Robust repeating, redundancy on channel 4 and 5
D = Robust repeating (auto baudrate detect)
E .. F = Same as 0
< 10 s (if it is set to auto detect)
At baudrate: Normal mode: Robust mode:
9.6 - 93.75 kbps ≤1.7 Tbit ≤13.25 Tbit
187.5 - 500 kbps ≤1.8 Tbit ≤13.30 Tbit
1.5 Mbps ≤1.9 Tbit ≤13.40 Tbit
3 Mbps ≤2.2 Tbit ≤13.60 Tbit
6 Mbps ≤3.0 Tbit ≤14.00 Tbit
12 Mbps ≤4.0 Tbit ≤15.00 Tbit
Max. ¼ bit time
