3.2.7 Termination Status
Input Identifier byte: 0x14
The next input byte is to indicate the status of the termination switches on the ProfiHub channels.
Bit Meaning
0
Main Channel termination ON
1
Channel 1 termination ON
2
Channel 2 termination ON
3
Channel 3 termination ON
4
Channel 4 termination ON
5
Channel 5 termination ON
Examples: 0x3F = All terminations are ON
0x01 = Only Main Channel termination is ON
0x10 = Only Channel 4 termination is ON
3.2.8 Channel Status
Input Identifier byte: 0x15
The next input byte is to indicate the communication status of the individual channels.
Bit Meaning
0
Communication on Main Channel
1
Communication on Channel 1
2
Communication on Channel 2
3
Communication on Channel 3
4
Communication on Channel 4
5
Communication on Channel 5
Examples: 0x08 = Communication on Channel 3
0x0A = Communication on Channels 1 and 3
0x2C = Communication on Channels 2, 3 and 5
3.2.9 Livelist Status
Input Identifier byte: 0x20
The next input byte is to indicate which Channel is selected to display the Livelist status.
Hex Meaning
80
Livelist of Main Channel
81
Livelist of Channel 1
82
Livelist of Channel 2
83
Livelist of Channel 3
84
Livelist of Channel 4
85
Livelist of Channel 5
86
Livelist of this ProfiHub
FF
Livelist of all channels (entire network)
