Format, so a maximum of 65535 decimal per statistic) or 4 bytes (Long Format) and is sent in the
following order:
1. Lost count
2. Sync count
3. Repeats total count
4. Repeats max per cycle count
5. Illegals count
6. Int. diagnostics count
7. Ext. diagnostics count
8. Diagnostics while in Data Exchange count
This module also has 2 output bytes. The first byte is used to configure the ProfiHub Statistics; you
can choose which stations or Channels will display statistics. Configure it by sending the following
output value:
Hex Meaning
00..7E
Statistics for device 0..126
7F
Statistics for undefined devices
80
Statistics of Main Channel
81
Statistics of Channel 1
82
Statistics of Channel 2
83
Statistics of Channel 3
84
Statistics of Channel 4
85
Statistics of Channel 5
86
Statistics of this ProfiHub
FF
Statistics of all channels (entire network)
The next output byte can be used for clearing the statistics. Please note that the selected statistics of
ALL node addresses and/or ProfiHub channels are cleared, not only for the displayed address or
channel.
Bit Meaning
0
Clear LOST statistics
1
Clear SYNC statistics
2
Clear REPEATS TOTAL statistics
3
Clear REPEATS MAX statistics
4
Clear ILLEGALS statistics
5
Clear INT. DIAG statistics
6
Clear EXT. DIAG statistics
7
Clear DIAG WHILE IN DX statistics
Example: To clear all LOST and ILLEGALS statistics, send 0x11
To clear all statistics, send 0xFF
