6 PRODIGIT
MODEL 3260A 32601A 32616A
LOAD INPUT RATINGS
Power (VA)
Current(Ampere)
Voltage(Volt)
1200 VA
12 Arms
50~300 Vrms
2400 VA
24 Arms
50~300 Vrms
12600VA
126Arms
60~300Vrms
PROTECTION：
Over Power Protection
Over Current Protection
Over Voltage Protection
Over Temp. Protection
≒ 1260 VA
≒ 12.6 A
≒ 315 V
85℃
≒ 2520 VA
≒ 25.2 A
≒ 315 V
85℃
≒ 13230 VA
≒ 132.3 A
≒ 315 V
85℃
Range 0~6/6~12 A 0~12/12~24 A 0 ~ 63/126 A
Resolution 1.5/3 mA 3/6 mA 15.75/31.5mA
Accuracy
±（ 0.5﹪ of setting ＋ 1﹪ of range ）；
±0.5﹪ of （setting ＋ range）@ 50/60Hz
0~0.6 A 0~1.2 A 0 ~ 6.3 A
CC MODE
&
Linear CC
MODE
Low
Current
Accuracy
± 2 % of (setting + range)
Range II/I
5~20~
80K
2.5~10~
40K
0.476~1.904~
7.616K
Resolution
0.013 /
0.052 mS
0.025 /
0.1 mS
0.5252S /
0.1313mS
Accuracy
±（ 0.5﹪ of setting ＋ 2﹪ of range ）；
±0.5﹪ of （setting ＋ range）@ 50/60Hz
CR MODE
Under 5 ﹪
F.S.Current
±2﹪ of （setting ＋ range）
Range
√2 ~ 3.5 / 1.5 ~ 1.9 / 3.0 ~ 3.4
CREST
FACTOR
(CCMODE
ONLY)
Resolution 0.5 / 0.1 / 0.1
VOLTAGE Range 300 V 300 V 300 V
READBACK Resolution 0.1 V 0.1 V 0.1 V
V METER Accuracy
±( 0.5﹪ of reading ＋ 0.2﹪of range )
DVM under 1% don’t display.
CURRENT Range 12 A 24 A 126 A
READBACK Resolution 0.001 A 0.01 A 0.014 A
A METER Accuracy
±（ 0.5﹪ of reading ＋ 2﹪ of range ）；
±0.5﹪ of （reading ＋ range）@ 50/60Hz
WATT Range 1200 W 2400 W 12600 W
READBACK Resolution 0.1 W 0.1 W 1 W
Accuracy
±（ 0.5﹪ of reading ＋ 2﹪ of range ）；
±0.5﹪ of （reading ＋ range）@ 50/60Hz
W METER
Under 5 ﹪
F.S.Current
±3﹪ of （setting ＋ range）
VA METER Vrms×Arms Correspond To Vrms and Arms
FREQUENCY Range DC , 40~400 Hz(CC Mode) ;
DC , 0.1~400 Hz(LIN,CR Mode)
Imonitor （Isolated） 3 A/V 6 A/V 31.5A/V
