Prodigit 3260A Series - Table 3-3 3260 A Initial Condition Setting; Table 3-4 3261 A Initial Condition Setting; Table 3-5 32611 A Initial Condition Setting

26 PRODIGIT
button is released.
Description Condition/Value Description Condition/Value
MODE CC C.F. √2
LOAD OFF FREQ FREQ = 60.0Hz
LEVEL A BANK = 0
SENSE OFF SYNC = OFF
PRES OFF CC LEVEL A 0.000A
WATT OFF CC LEVEL B 0.000A
LIMIT V LIMIT = 400.0V LIN LEVEL A 0.000A
A LIMIT = 20.00A LIN LEVEL B 0.000A
W LIMIT = 2000.0W CR LEVEL A 80E3Ω
VA LIMIT = 2000.0W CR LEVEL B 80E3Ω
Table 3-3 3260A Initial Condition Setting
Description Condition/Value Description Condition/Value
MODE CC C.F. √2
LOAD OFF FREQ FREQ = 60.0Hz
LEVEL A BANK = 0
SENSE OFF SYNC = OFF
PRES OFF CC LEVEL A 0.000A
WATT OFF CC LEVEL B 0.000A
LIMIT V LIMIT = 400.0V LIN LEVEL A 0.000A
A LIMIT = 20.00A LIN LEVEL B 0.000A
W LIMIT = 2000.0W CR LEVEL A 53E3Ω
VA LIMIT = 2000.0W CR LEVEL B 53E3Ω
Table 3-4 3261A Initial Condition Setting
Description Condition/Value Description Condition/Value
MODE CC C.F. √2
LOAD OFF FREQ FREQ = 60.0Hz
LEVEL A BANK = 0
SENSE OFF SYNC = OFF
PRES OFF CC LEVEL A 0.000A
WATT OFF CC LEVEL B 0.000A
LIMIT V LIMIT = 400.0V LIN LEVEL A 0.000A
A LIMIT = 40.00A LIN LEVEL B 0.000A
W LIMIT = 4000.0W CR LEVEL A 26E3Ω
VA LIMIT = 4000.0W CR LEVEL B 26E3Ω
Table 3-5 32611A initial Condition Setting
