24 PRODIGIT
3-4 Setting of Freq. & Selection of Bank & Sync.
3.4.1 Frequency Setting:
The range for setting the frequency of 3260A Series High Power AC/DC Electronic
Load is from DC , 0.1 ～ 400.0 Hz.
The authorization for setting the frequency of 3260A Series High Power AC/DC
Electronic Load is the frequency output by U.U.T. Upon completion of setting, the
SYNC trigger setting has to be set to OFF and the setting value of such a frequency
will be valid. If the frequency setting is less than 40 Hz, the frequency setting value
shall be set automatically to DC.
3.4.2 Bank Selection:
3260A Series High Power AC/DC Electronic Load provides 11 built-in sets totaling 55
wave form information. The content of Bank is as shown in Table 3-2. Please refer to
Appendix for details.
Note： When Frequency is set to DC, the wave form information shall be fixed at DC level,
also, this Bank selection function will not be provided until after Frequency is set to
AC.
BANK A B C D E
SINE WAVE
0 √2 2.0 2.5 3.0 3.5
1 1.5 1.6 1.7 1.8 1.9
2 3.0 3.1 3.2 3.3 3.4
C.F.= 2.0 3 P.F.=-0.85
P.F.=-0.80
P.F.=-0.75
P.F.=-0.70
P.F.=-0.65
C.F.= 2.5 4 P.F.=-0.70
P.F.=-0.65
P.F.=-0.60
P.F.=-0.50
P.F.=-0.40
C.F.= 3.5 5 P.F.=-0.50
P.F.=-0.45
P.F.=-0.40
P.F.=-0.35
P.F.=-0.30
C.F.= 2.0 6 P.F.=0.85
P.F.=0.80
P.F.=0.75
P.F.=0.70
P.F.=0.65
C.F.= 2.5 7 P.F.=0.70
P.F.=0.65
P.F.=0.60
P.F.=0.50
P.F.=0.40
C.F.= 3.5 8 P.F.=0.50
P.F.=0.45
P.F.=0.40
P.F.=0.35
P.F.=0.30
Square Wave
9 1 1.1 1.2 1.3 1.4
DC 10 √2dc 2dc 2.5dc 3.0dc 3.5dc
Table 3-2 3260A Built-In Wave Form Data Bank
