Prodigit 3260A Series - Table 3-11 3260 A Series Rough Tuning, Fine Tuning & Increment & Decrement Adjustment of Load Current

PRODIGIT 3260A Series Operation Manual 31
32613A Range I Range II
FULL SCALE LOAD CURRENT 36 A 72 A
CURRENT RANGE 72.000 A
METER RESOLUTION 0.012 A
COURSE/FINE LOAD
CURRENT ADJUSTMENT KEY
KEY’S STEP RESOLUTION 90 mA 9 mA 180 mA 18 mA
32615A Range I Range II
FULL SCALE LOAD CURRENT 54 A 108 A
CURRENT RANGE 108.000 A
METER RESOLUTION 0.012 A
COURSE/FINE LOAD
CURRENT ADJUSTMENT KEY
KEY’S STEP RESOLUTION 135 mA 13.5 mA 270 mA 27 mA
32616A Range I Range II
FULL SCALE LOAD CURRENT 63 A 126 A
CURRENT RANGE 126.00 A
METER RESOLUTION 0.014 A
COURSE/FINE LOAD
CURRENT ADJUSTMENT KEY
KEY’S STEP RESOLUTION 157.5 mA 15.75 mA 315 mA 31.5 mA
Table 3-11 3260A Series Rough Tuning, Fine Tuning & Increment & Decrement Adjustment of Load
Current
