2. About the Device
This chapter provides an overview of the device’s operating elements and functions as well as the intended use of the
device. Additionally, it provides an overview of the available Models/Types and certificates.
For more detailled information, see Chapter Annex.
2.1. Important Device Information
2.1.1. Device Elements
Figure 2. Device overview CANlink wireless 4000
Table 1. Device Overview
# Item
1 Main plug connector
2 Housing
3 Type label top
4 LED On
5 LED Status
6 RF antenna connector
7 Type label bottom
8 Mounting holes
CANlink wireless 4000 Device Manual
