5.3. Configuring the Device
The following chapters will give an overview of the required configuration settings for the several options which are
mentioned in the Use Cases Overview.
The settings for each section, the tabs Device, WLAN, Bluetooth and Wireless Peers are listed in separate
tables.
Figure 32. CANlink wireless configurator Tabs
In this document, only the basic settings for the individual connection methods are listed. Further details on
how to configure the CANlink wireless 4000, can be found in the CANlink wireless Configurator manual at the
Document Library.
ļ
The default configuration for the CAN Receive settings already has active receive objects with
open filter masks for all 11bit and 29bit CAN message identifiers. So this tab is not considered in
the configuration instruction for the application examples from the Use Cases Overview. Please
also note that the default CAN baudrate of the device is set to 250 kbit/s. Adapt the CAN baudrate
in the configuration if required.
CANlink wireless 4000 Device Manual
