Online CAN object Binary
11-bit CAN identifier (hex): 0x124
001 0010 0100
11-bit CAN identifier (hex): 0x125
001 0010 0101
XNOR gate for filter mask
111 1111 1000
Resulting Filter mask (hex) 0x7F8
111 1111 1xxx
Filter Calculation Example 3:
CAN messages with the CAN identifiers 0x123, 0x124, and 0x125, 0x621, and 0x726 are transmitted. The required
filter mask must be determined using an XNOR gate. Other CAN messages that comply with the filter mask are also
received. CAN messages with other CAN identifiers are not received, but forwarded to the next online CAN object.
Table 47. Example 3: Filter mask for CAN messages
Online CAN object Binary
11-bit CAN identifier (hex): 0x123
001 0010 0011
11-bit CAN identifier (hex): 0x124
001 0010 0100
11-bit CAN identifier (hex): 0x125
001 0010 0101
11-bit CAN identifier (hex): 0x621
110 0010 0001
11-bit CAN identifier (hex): 0x726
111 0010 0110
XNOR gate for filter mask
000 1111 1000
Resulting Filter mask (hex) 0xF8
xxx 1111 1xxx
