Figure 4. CANlink wireless 4000 type label bottom
Table 3. Device Type labels
# Item
1 Manufacturer address
2 Country of origin
3 ECE certification mark
NOTICE
Use of solvents on the product label can remove or destroy product information.
- Keep solvent-containing substances away from the label!
NOTICE
Loss of connectivity at devices with internal antenna.
- Please do not stick additional labels onto the device. Depending on the nature of the material,
these stickers can severely impair the signal quality.
INFORMATION
The device’s type label contains important information.
- Do not remove the type label.
Traceability code
The traceability code contains the following information.
Example:
253001072000000000001907492(W)D4CA6E868CDE(B)D4CA6E868CDD
Table 4. Extracted information
Item Description
9-digit part number: 253001072 (P/N depends on Type)
Serial number 0-padded:
1907492
(W) followed by the WLAN MAC Address:
D4CA6E868CDE
CANlink wireless 4000 Device Manual
