4 Memory Organization
Address
Intel Mot.
Name Bit No. Significance
30H R_Prm_Buf_Ptr Segment base address of the Prm_Buf
31H R_Len_Cfg_Data Length of the input data in the Cfg_Buf
32H R_Cfg_Buf_Ptr Segment base address of the Cfg_Buf
33H
R_Len_Read_Cfg_Data
Length of the input data in the
Read_Cfg_Buf
34H R_Read_Cfg_Buf_Ptr
Segment base address of the
Read_Cfg_Buf
35H R_Len_DXB_Link_Buf Length of the DXB_Linktable
36H R_DXB_Link_Buf_Ptr
Segment base address of the
DXB_Link_Buf
37H R_Len_DXB_Status_Buf Length of the DXB_Status
38H R_DXB_Status_Buf_Ptr
Segment base address of the
DXB_Status_Buf
39H R_Real_No_Add_Change
This parameter specifies whether the
Station_Address may be changed again
later.
3AH R_Ident_Low
The user sets the parameters for the
Ident_Number_Low value.
3BH R_Ident_High
The user sets the parameters for the
Ident_Number_High value.
3CH R_GC_Command
The Control_Command of Global_Control
last received
3DH R_Len_Spec_Prm_Buf
If parameters are set for the
Spec_Prm_Buffer_Mode (see Mode
Register 0), this cell defines the length of
the Prm_Buf.
3EH R_DXBout_Buf_Ptr2 Segment base address of DXBout_Buf 2
3FH R_DXBout_Buf_Ptr3 Segment base address of DXBout_Buf 3
Figure 4-4: Assignment of the Organizational Parameters
