PROFIBUS DP Interface 6

Structure of the Set_Slave_Add Telegram

The net data are stored as follows in the SSA buffer:

Bit Position

Byte

7 6 5 4 3 2 1 0

Designation

0 New_Slave_Address

1 Ident_Number_High

2 Ident_Number_Low

3 No_Add_Chg

243

Rem_Slave_Data

additional application

specific data

Figure 6-4: Structure of the Set_Slave_Add Telegram

6.2.2 Set _Prm (SAP 61)

Parameter Data Structure

The VPC3+C evaluates the first seven data bytes (without

User_Prm_Data), or the first eight data bytes (with User_Prm_Data). The

first seven bytes are specified according to the standard. The eighth byte is

used for VPC3+C specific characteristics. The additional bytes are

available to the application.

If a PROFIBUS DP extension shall be used, the bytes 7-9 are called

DPV1_Status and must be coded as described in section 7,

“PROFIBUS DP Extensions”. Generally it is recommended to start the

User_Prm_Data first with byte 10.
