6 PROFIBUS DP Interface
Bit Position
Byte
7 6 5 4 3 2 1 0
Designation
0
Lock_ Req Unlock_ Req Sync_ Req Freeze_ Req WD_On Reserved Reserved Reserved
Station Status
1 WD_Fact_1
2 WD_Fact_2
3 minT
SDR
4 Ident_Number_High
5 Ident_Number_Low
6 Group_Ident
7
DPV1_
Enable
Fail_Safe
Publisher_
Enable
0 0
WD_Base Dis_Stop_ Control Dis_Start_ Control
Spec_User_Prm_Byte
/DPV1_Status_1
8 DPV1_Status_2
9 DPV1_Status_3
10
:
243
User_Prm_Data
Figure 6-5: Format of the Set_Prm Telegram
