5 ASIC Interface
Status Register, High-Byte, Address 05H (Intel):
bit 15-12
VPC3+-Release 3..0 : Release number for VPC3+
0000 = Step A
1011 = Step B
1100 = Step C
1101 = Step D
Rest = Not possible
bit 11-8
Baud Rate 3..0 : The baud rate found by VPC3+D
0000 = 12,00 Mbit/s
0001 = 6,00 Mbit/s
0010 = 3,00 Mbit/s
0011 = 1,50 Mbit/s
0100 = 500,00 Kbit/s
0101 = 187,50 Kbit/s
0110 = 93,75 Kbit/s
0111 = 45,45 Kbit/s
1000 = 19,20 Kbit/s
1001 = 9,60 Kbit/s
1111 = after reset and during baud rate search
Rest = not possible
Figure 5-6: Status Register, High-Byte
