PROFIBUS DP Interface 6
According to IEC 61158, Static Diagnosis should only be used during
tart-up.
e possible codings for
oth buffers: User, VPC3+, or VPC3+_Send_Mode.
s
Status coding for the diagnosis buffers is stored in the Diag_Buffer_SM
control parameter. The user can read this cell with th
b
Bit Position
Address
7 6 5 4 3 2 1 0
Designation
0CH 0 0 0 0 Diag_Buf2 Diag_Buf1 Diag_Buffer_SM
Diag_Buffer_SM, Address 0CH:
bit 7-4
Don’t care: Read as ‘0’
bit 3-2
f2: Assignment of Diagnosis Buffer 2
11 = VPC3_Send_Mode
Diag_Bu
00 = Nil
01 = User
10 = VPC3+
bit 1-0
f1: Assignment of Diagnosis Buffer 1
11 = VPC3_Send_Mode
Diag_Bu
00 = Nil
01 = User
10 = VPC3+
Figure 6-9: Diagnosis Buffer Assignment
e currently assigned to the VPC3+C (No_Buffer,
iag_Buf1, Diag_Buf2).
The New_Diag_Cmd is also a read access to a defined control parameter
indicating which Diagnosis-Buffer belongs to the user after the exchange or
whether both buffers ar
D
Bit Position
Address
7 6 5 4 3 2 1 0
Designation
0DH 0 0 0 0 0 0
⇓ ⇓
New_Diag_
Buffer_Cmd
0 0 No_Buffer
0 1 Diag_Buf1
1 0 Diag_Buf2
Figure 6-10: Coding of New_Diag_Cmd
VPC3+C User Manual
Revision 1.03 45
