What causes ProFire PF2100 status contact to remain closed when the system is stopped?
If the status contact on your ProFire Controller remains closed even when the system is stopped, the status contacts are polarity sensitive. Try reversing the Status+ and Status- wires.
How to fix ProFire PF2100 Controller status contact that never closes?
If the status contact on your ProFire Controller never closes, the current or voltage ratings on the status contact may have been exceeded. Verify that you are not exceeding these ratings. If the ratings were exceeded, check the terminal Card HW version to determine the appropriate solution: for v1.6, replace the Terminal Card; for v1.7, replace the Status Contact Fuse on the Terminal Card.
Why is my ProFire PF2100 solar output voltage 12V when 24V is expected?
If your ProFire Controller's solar output voltage is 12V when 24V is expected, check the solar panel wiring. They should be wired in parallel rather than in series.
How to fix ProFire PF2100 status contact that opens but system continues to run?
If the status contact on your ProFire Controller opens but the system continues to run, check that the system has the latest firmware. Some firmware versions older than v1.8.005 had a bug that might lead to this under certain circumstances. If you can’t update your firmware immediately, repositioning the flame rod so that it is more fully immersed in the flame can lessen the occurrence of this issue.
How to write setpoints via Modbus on ProFire PF2100 Controller?
To write setpoints via Modbus on your ProFire Controller, ensure the system has the latest firmware (firmware older than v1.8.005 did not support this feature) and that the Modbus Card has the latest firmware (firmware older than v4.0 did not support this feature).
What to do if ProFire PF2100 system shuts down on TCS not being equal?
To resolve a shutdown on your ProFire Controller system due to TCS not being equal, follow these steps: 1. Press the Up and Down arrows together. 2. Go to the calibration menu. 3. Step through the menu to Cal High Temp = xxxC. 4. Press the Up arrow once. 5. Press OK. 6. Go back to the screen with the temperature readings and make sure the issue is corrected.
Crucial safety guidelines for installation and operation.
Critical warnings and precautions before proceeding with installation.
Detailed instructions and precautions for wiring the system components.
Explains how the system monitors and adjusts temperature for process control.
Lists common problems and their corresponding solutions for quick resolution.
Lists system shutdown messages and their potential solutions.
Provides a list of alarm codes, their meanings, and troubleshooting steps.
Step-by-step guide for troubleshooting flame detection issues.
Guide for troubleshooting issues related to thermocouple readings and connections.
General| Brand | ProFire |
|---|---|
| Model | PF2100 |
| Category | Controller |
| Language | English |
