Proline PL-DPF 804B - Location of Controls; Connectivity Ports; On-Frame Controls

5
Location of Controls
1. SD/MMC/MS-card slot
2. CF-card slot
3. USB HOST for connecting the USB device directly.
4. USB device port for connecting the computer
5. DC 9V 1.5A Port
6. Frame base
7. [X] Touch to start or pause slideshow or confirm the
selection.
8. [
] Touch to return to the main menu. Touch and hold to display the OSD
menu while viewing photos.
9. [2] Touch to return to the previous menu.
10. [g] Touch to move the cursor left or rotate the picture
11. [h] Touch to move the cursor right or rotate the picture.
12. [i] Touch to move the cursor up or select the previous picture
13. [j] Touch to move the cursor down or select the next picture.
