To start the datalogger:
After creating a new datalogger file or selecting an existing one, the
user can start the datalogging process.
From the datalogger viewer screen, press the "Test point" key and
from the menu select an existing test point using the "Go to ..." option
or "Create new ..." to create a new test point. If a new test point is
created, user has to give it a name.
Now datalogger is ready to start. Press the "Datalogger" key
and
select "Start".
During datalogger, it catches the list of available services of all
channels in the channel set that are part of the datalogger (if this
option was selected when creating the datalogger or if the "Datalogger
PSI" option is enabled in the Preferences menu). If there is a change
of channel set during datalogger there will be a pause (if this option
was sele edct when creating the datalogger). User can pause and
resume the datalogger process at any time by pressing on the key
"Pause"
.
At the end it saves the data and allows watching the results on screen
by channel set. To change the channel set press on the
key.
Datalogger can be saved on a PC using the PkUpdate software,
available on the PROMAX website. Information about service lists are
in the XML files, which can be downloaded to a PC.
April 2013
6-73
