Exploded diagrams of liquid ends
Liquid end 0708 (1008) - 0220 (0420)
PP / NP self-degassing
The listed items are included in the spare parts kit.
Subject to technical alterations.
Spare parts kits for:
Type Material Order No.
0708 (1008) PPE 1001759
0413 (0713) PPE 1001760
0220 (0420) PPE 1001761
0708 (1008) PPB 1001765
0413 (0713) PPB 1001766
0220 (0420) PPB 1001767
0708 (1008) NPE 1001663
0413 (0713) NPE 1001664
0220 (0420) NPE 1001665
0708 (1008) NPB 1001669
0413 (0713) NPB 1001670
0220 (0420) NPB 1001671
1 valve ball 404201
3 valve balls 404281
Diaphragm 0708 1000248
Diaphragm 0413 1000249
Diaphragm 0220 1000250
1 seal set EPDM 1001675
1 seal set FPM 1001673
Suction valve set PPE 1001437
Suction valve set PPB 1001436
Suction valve set PCE 1001435
Suction valve set PCB 1001434
Discharge valve set PPE 1001071
Discharge valve set PPB 1001070
Discharge valve set PCE 1001069
Discharge valve set PCB 1001068
Connector kit 6/4 PPE 817160
Connector kit 6/4 PPB 817173
Connector kit 6/4 PCE 791161
Connector kit 6/4 PCB 817065
Connector kit 8/5 PPE 817161
Connector kit 12/9 PPE 817162
Connector kit 8/5 PPB 817174
Connector kit 12/9 PPB 817175
Connector kit 8/5 PCE 792058
Connector kit 12/9 PCE 790577
Connector kit 8/5 PCB 817066
Connector kit 12/9 PCB 817067
Connector kit 8/5 PPE 817161
Connector kit 12/9 PPE 817162
Connector kit 8/5 PPB 817174
Connector kit 12/9 PPB 817175
Connector kit 8/5 PCE 792058
Connector kit 12/9 PCE 790577
Connector kit 8/5 PCB 817066
Connector kit 12/9 PCB 817067
Vent valve PPE 1001063
Vent valve PPB 1001062
Vent valve PCE 1001061
Vent valve PCB 1001060
