ProMinent
®
Page 38
Technical Data
14.6 Ambient conditions
Temperatures Storage and transport temperatures: –10 to +50 °C
Feed chemical temperature: –10 to +35 °C
Ambient temperature when in operation: –10 to +45 °C (drive and control)
Maximum ambient temperatures for liquid ends depending on material type:
erutarepmettneibma.xaM BPP,EPP BCP,ECP BPN,EPN TTT TSS
gnitarepo.xamtamret-gnoL
:erusserp
C°05*C°54C°54C°05C°05
)nim51.xam(mret-trohS
:rab2.xamta
C°001C°06C°06C°021C°021
* Under extreme conditions such as maximum dosing temperatures, maximum stroke
frequency and maximum operating pressure, leakage can occur on the liquid end at an
ambient temperature of 35 °C.
Climate Permissible air humidity: 92 % relative humidity, not condensing
Moist and fluctuating air conditions: FW 24 in accordance with DIN 50016
14.7 Enclosure rating and safety class
Enclosure Rating Contact and moisture enclosure rating: IP 65 in accordance with IEC 529, EN 60529, DIN VDE
0470 Part 1
Safety Requirements Safety Class 1 - Mains connection with earth lead
14.8 Compatibility
The hydraulic parts of the gamma/ L are identical to those of the Beta
®
.
The following components and accessories for pumps from the product ranges Beta
®
,
CONCEPT, gamma-Classic and gamma are all compatible:
• gamma/Vario signal cable; 2-, 4- and 5 core for “external” function
• 2 stage float switch (gamma/Vario)
• Discharge tubing diameters
• Standard gamma connector set
• gamma wall bracket
• Chemical feed containers and mounting plates
• Total height (distance between suction and discharge connector)
• Distance between the connectors and locating holes on the pumps
• Accessories such as pressure back pressure valve, multifunctional valve, dosing monitor
and rinsing equipment
