ProMinent
®
GALA Series gamma/ L, version a
Type Capacity
bar l/h
1000 10 0,74
1601 16 1,1
1602 16 2,1
1005 10 4,4
0708 7 7,1
0413 4 12,3
0220 2 19,0
1605 16 4,1
1008 10 6,8
0713 7 11,0
0420 4 17,1
0232 2 32,0
Material version:
PPE Polypropylene/EPDM
PPB Polypropylene/FPM (Viton
®
)
PCE PVC/EPDM
PCB PVC/FPM (Viton
®
)
NPE Acrylic glass/EPDM
NPB Acrylic glass/FPM (Viton
®
)
TTT PTFE/PTFE
SST Stainless steel 1.4571/PTFE
Liquid end version:
0 Non-bleed, no valve spring, for NP, TT and SS only
1 Non-bleed, with valve spring, for NP, TT and SS only
2 Bleed function, no valve spring for PP, PC, NP, not type 0232
3 Bleed function, no valve spring for PP, PC, NP, not type 0232
9 Self bleed function, for PP, NP, not for type 1000 and 0232
Hydraulic connection:
0 Standard connector as indicated in technical data
5 12/6 hose connector, pressure side only
9 10/4 hose connector, pressure side only
Version:
0 With ProMinent
®
logo
Power supply:
U 100 - 230 V, ±10 %, 50/60 Hz
Cabel and plug:
A 2 m Euro
B 2 m Swiss
C 2 m Australian
D 2 m USA
Relay:
0 No relay
1 Fault indicating relay, (N/C) changeover relay
3 Fault indicating relay, (N/O) changeover relay
4 As 1 + pacing relay, (1 input each)
5 As 3 + pacing relay, (1 input each)
Accessories:
0 No accessories
1 Foot and dosing valve,, 2 m PVC suction tube,
5 m PE discharge tubing, PP, PC, and NP only
2 As 0 + calibrating cylinder
3 As 1 + calibrating cylinder
Control variants:
0 Manual + external 1:1
1 Manual + external with pulse control
2 Manual + external 1:1 with analogue current
3 Manual + external with pulse control + analoque current
Access code:
0 No access code
1 Access code
Dosing monitoring:
0 Pulse input
1 Input for continuous contact
Pause/level:
0 Pause N/C/level N/C
GALA 1602 PPE 2 0 0 U A 0 0 0 0 0 0
Identcode
Viton
®
(FPM) is a registered trademark of DuPont Dow Elastomers.
Solenoid Æ 70/M70
Solenoid Æ 85/M85
