Type Pump capacity Connector
size
outer Æ x
inner Æ
Suction lift
1
Priming
lift
2
Max. priming
pressure on
the suction
side
5, 6
bar l/h ml/stroke mm m water
column
m water
column
bar
1009 10 8.0 0.67 8x5 3.0 - 5
0715 7 13.5 1.12 8x5 2.5 - 3.5
0424 4 20.0 1.67 12x9 2.5 - 2
5
The pressure on the discharge side needs to be at least 1.5 bar higher than the pressure on the suction
side. We therefore recommend installing a back pressure valve on the discharge side to adjust the
increased pressure. This will avoid excess pumping.
6
If the pump is fitted with an SER head and priming pressure is being applied, then the pump may only be
operated in Automatic OFF mode.
* - The capacity can significantly fall at pressures above the
nominal pressure.
*** - with stainless steel design 6 mm connector width
**** - with stainless steel design 12 mm connector width
***** - The SER valve is only approved up to a pressure of 10 bar.
We recommend operating a pump with a SER valve of
between 1 ... 7 bar.
1 - Suction lift with a filled suction line and filled liquid end.
With self-degassing dosing head with air in the suction line.
2 - Priming lifts with clean and moist valves. Priming lift at
100%
stroke length and free drainage or opened vent
valve.
3 - The given performance data represents guaranteed min‐
imum values calculated using water as the medium at room
temperature. The bypass connection with a self-degassing
dosing head SEK is 6x4 mm.
4 - These pump types are also available with dosing heads for
higher-viscosity media (HV). The pump types have a
10 ... 20% lower capacity and are not self-priming.
All data is calculated with water at 20 °C.
17.1.1 Performance data with vPTFE diaphragm
Tab. 27: gamma/ X with 200 strokes/minute and 100% stroke length
Type
... PVT
Minimum pump capacity *
at maximum back pressure
Connector
size
outer Æ
x
inner Æ
Suction
lift**
Priming
lift***
Max. pri‐
ming pres‐
sure on the
suction
side
bar l/h ml/stroke mm m water
column
m water
column
mbar
gamma X
1602 ... 10 2.04 0.17 6x4 5 2 5.5
1604 ... 10 3.24 0.28 6x4 5 2 3
Technical data
116
