Type
... PVT
Minimum pump capacity *
at maximum back pressure
Connector
size
outer Æ x
inner Æ
Suction
lift**
Priming
lift***
Max. pri‐
ming pres‐
sure on the
suction
side
bar l/h ml/stroke mm m water
column
m water
column
mbar
0708 ... 7 7.6 0.66 8x5 4 2 2
1009 ... 10 9.0 0.76 8x5 3 2 2
0414 ... 4 11.52 0.94 8x5 3 2 1.5
0715 ... 7 10.2 1.03 8x5 3 2 1.5
0220 ... 2 16.56 1.48 12x9 2 2 1
0424 ... 4 19.8 1.79 12x9 3 2.5 1
0245 ... 2 35.64 3.1 12x9 2 2 0.8
* The stated performance data represents minimum values calculated using water as the medium at 20 °C.
** Suction lift with a filled suction line and filled liquid end.
*** Priming lifts with clean and moist valves. Priming lift at
100% stroke length and free drainage or opened
vent valve.
17.2 Accuracy
17.2.1
Standard Liquid End
Data Value Unit
Capacity range of the series -5 ... +10 % *
Reproducibility ±2 % **
* - at max. stroke length and max. operating pressure for all
material versions
** - at constant conditions and min. 30 % stroke length
17.2.2 Self-Bleeding Liquid End
As the self-bleeding liquid end is used with outgassing media and
when operating with air bubbles, no dosing accuracy or reproduci‐
bility can be provided.
The recommended minimum stroke length with self-bleeding
dosing pumps is 50 %.
Technical data
117
