6.9 Hierarchy of operating modes, functions and fault statuses
The different operating modes, functions and fault statuses have a
different impact on whether and how the pump reacts.
The following list shows the order:
1. - Priming
2. - Stop
3. - Error, Pause
4. - Auxiliary capacity / Auxiliary frequency
5. - Manual, Analog, Contact, Batch, Fieldbus
Comments:
re 1. - "Priming" can take place in any pump mode (providing it is
working).
re 2. - "Stop" stops everything.
re 3. - "Error", and "Pause" stop everything apart from "Priming".
re 4. - "Auxiliary capacity" and/or "Auxiliary frequency" always
have priority over the capacity / stroke rate specified by an
operating mode listed under 5.
Functional description
29
