5.2 Control elements
11 13
14
12
3
1
5
4
2
10
987
6
a)
b)
P_G_0051_SW
Fig. 5: Control elements
1 LCD screen
2
[Menu]
key
3
Clickwheel
4
[Priming]
key
5
[STOP/START]
key
6
[Back]
key
7 Fault indicator (red)
8 Warning indicator (yellow)
9 Operating indicator (green)
10 "Diaphragm rupture indicator" terminal
11 "External control" terminal
12 "Metering monitor" terminal
13 "Level switch" terminal
14 Slot for relays and optional modules
5.2.1 Control elements
Use this overview to familiarise yourself with the
keys and other control elements on the pump!
Control elements, overview
Overview of equipment and control elements
18
