7 Assembly
Please refer to the online version of the operating
instructions on our website for the right dimen‐
sional drawings for the pump and mounting plate.
Compare the dimensions on the dimensional
drawing with those of the pump and/or mounting
plate.
CAUTION!
Danger from incorrectly operated or inadequately
maintained pumps
Danger can arise from a poorly accessible pump
due to incorrect operation and poor maintenance.
– Ensure that the pump is accessible at all times.
–
Adhere to the maintenance intervals.
Capacity too low
The liquid end valves can be disturbed by vibra‐
tions.
–
Secure the metering pump so that no vibra‐
tions can occur.
Capacity too low
If the valves of the liquid end are not vertical, they
cannot close correctly.
–
Ensure that the suction and discharge valves
are upright (with self-bleeding liquid ends: the
bleed valve).
Several metering pumps can be arranged closely
together as required.
1. To remove the mounting plate, press down the black flap
below the front of the pump a little and press the mounting
plate backwards.
2. Assemble the mounting plate on a level and load-bearing
base surface (with a minimum of 2 bolts and 2 washers!).
You can also assemble the mounting plate on a vertical, level
and load-bearing base surface (using 3 bolts and 3
washers!). You then need to rotate the liquid end (vertical
valve position!)
You can also assemble the mounting plate on a wall bracket
(accessories). 3 alignments are possible.
3. Lock the foot of the metering pump into the mounting plate –
see Fig. 10.
