ProMinent gamma/ X User Manual

n Dosing tanks and fixing plates
n Distance between suction and pressure connector
n Distance between the connectors and the pump fixing holes
n Distance between the pump fixing holes
n Identical use of accessories, such as back pressure valves, multifunc‐
tional valves and flushing assembly
n Compatibility of resistance by the equivalence of the material used for
the liquid ends
Compatibility to the gamma/ L product range is not guaranteed for the fol‐
lowing points:
n External dimensions of the pump
n Distance between the support surface for the mounting foot and the
centre of the dosing head
n Dosing monitor
17.10 Shipping Weight
Material Types
2002, 1602, 1604, 0708, 0414, 0220 2504, 1009, 0715, 0424, 0245
PP, NP, PV, TT 3.6 .. 3.7 4.9 … 5.2
SS 4.1 … 5.0 5.5 … 7.0
17.11 Sound pressure level
Sound pressure level LpA < 70 dB according to EN ISO 20361
at maximum stroke length, maximum stroke rate, maximum back pressure
(water)
Shipping weight of gamma/ X types - in kg
Sound pressure level
Technical Data
82

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
