ProMinent gamma/ X User Manual

20 Diagrams for Setting the Capacity
0
1,0
2,0
3,0
4,0
5,0
6,0
7,0
8,0
9,0
0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
90
80
70
100
50
40
30
20
10
60
0
2,0
4,0
6,0
8,0
10,0
12,0
14,0
16,0
0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
90
80
70
100
50
40
30
20
10
60
0
0,5
1
1,5
2
2,5
3
0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
90
80
70
100
50
40
30
20
10
60
200 1/min
180 1/min
160 1/min
140 1/min
120 1/min
100 1/min
80 1/min
60 1/min
40 1/min
20 1/min
C [l/h] f [%]
s [%]
GMXa 0708
C [l/h] f [%]
s [%]
GMXa 0414
C [l/h] f [%]
s [%]
GMXa 1602
200 1/min
180 1/min
160 1/min
140 1/min
120 1/min
100 1/min
80 1/min
60 1/min
40 1/min
20 1/min
200 1/min
180 1/min
160 1/min
140 1/min
120 1/min
100 1/min
80 1/min
60 1/min
40 1/min
20 1/min
0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
90
80
70
100
50
40
30
20
10
60
C [l/h] f [%]
s [%]
GMXa 1604
200 1/min
180 1/min
160 1/min
140 1/min
120 1/min
100 1/min
80 1/min
60 1/min
40 1/min
20 1/min
Fig. 66: Capacity C at medium back pressure depending on the stroke length s for different stroke rates f
Diagrams for Setting the Capacity
125

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
