ProMinent gamma/ X User Manual

11 Set Up /
‘Menu’
–
Please also refer to all overviews covering "Operating/
set up overview" and "Operating menu for gamma/ X,
complete" in the appendix and in the chapters "Overview
of Equipment and Control Elements".
– The pump leaves the menu and returns to a continuous
display if
[Menu] is pressed or no key is pressed for
60 seconds.
The ‘Menu’ is sub-divided as follows:
1 - ‘Information’
2 - ‘Settings’
3 - ‘Service’
4 - ‘Language’
11.1 Information
‘Menu / Information è ...’
The ‘Information’ provides information on your pump and certain parame‐
ters and counters. The number and type can depend on the pump set‐
tings.
11.2
‘Settings’
‘Menu / Information è Settings è ...’
The ‘Settings’ menu generally includes these setting menus:
1 - ‘Operating mode’
2 - ‘Automatic’
3 - ‘Stroke length’
4 - ‘Metering’
6 - ‘Calibrate’
7 - ‘System’
8 - ‘Inputs/outputs’
9 - ‘Bleed valve’
10 - ‘Priming time’
11 - ‘Time’
12 - ‘Date’
11.2.1 Operating Mode
‘Menu / Information è Settings è Operating mode è ...’
Set Up /
‘Menu’
45

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
