ProMinent gamma/ X User Manual

1 Identity code
Product range gamma/ X
GMXa Type
- - - - Performance data and type - see nameplate
Dosing head material
PP Polypropylene
NP Clear acrylic
PV PVDF
TT PTFE + carbon
SS Stainless steel
Seal material
B FPM
E EPDM
T PTFE
Dosing head design
0 Without bleed valve, without valve spring
1 Without bleed valve, with valve spring
2 With bleed valve, without valve spring
3 With bleed valve, with valve spring
4 Without bleed valve, with valve spring for more high-viscosity media
9 Self-bleeding with bypass (SEK)
Hydraulic connector
0 Standard connection in line with technical data
5 Connector for 12/6 hose, suction side standard
9 Connector for 10/4 hose, discharge side only, suction side standard
Diaphragm rupture indicator
0 Without diaphragm rupture indicator
1 With diaphragm rupture indicator, optical sensor
Design
0 Hous. RAL5003 / Hood RAL2003
M modified
Logo
0 with ProMinent logo
Electrical connection
U Universal control 100-230 V ±10%, 50/60 Hz
Cable and plug
A 2 m European
B 2 m Swiss
C 2 m Australian
D 2 m USA / 115 V
E 2 m Great Britain
Identity code
5

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
