ProMinent gamma/ X User Manual

11.3.2
‘Password ’
‘Menu / Information è Service è Password è ...’
You can enter a password of your choice in the ‘Change password’ menu.
11.3.3
‘Clear Counter’
‘Menu / Information è Timer è Clear counter è ...’
You can reset the counter to "0" in the ‘Clear counter’ menu:
n
‘Stroke counter’ (total number of strokes)
n
‘Volume counter’ (total litres)
n
‘Contact memory’
n ‘All’
To clear: exit the menu by briefly pressing the [Clickwheel] .
The values have increased since commissioning of the pump, the last cali‐
bration or the last deletion.
11.3.4
‘Diaphragm Replacement’
‘Menu / Information è Service è Diaphragm replacement è ...’
You can move the slide rod into the "replacement position" here with ‘To
replacement position’ to enable the diaphragm to be replaced more easily.
11.3.5
‘Display’
‘Menu / Information è Service è Display è ...’
You can set the ‘Contrast’ and the ‘Brightness’ of the LCD screen here.
11.3.6
‘Reset to Factory Settings’
‘Menu / Information è Service è Reset to factory settings è ...’
You can reset the pump to its factory settings here with ‘Yes’
11.4 ‘Language’
‘Menu / Information è Language è ...’
In the ‘Language’ menu, you can select the desired operating language.
Set Up /
‘Menu’
63

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
