ProSun V3 - Electromagnetic Immunity Guidance; Immunity Test Levels and Environments

30
MARK76V3002 Rev 3
Guidance and Manufacturer’s Declaration - Electromagnetic Immunity
The ProSun V3 Model 42V3 isintendedforuseintheelectromagneticenvironmentspecied
below. The customer or the user of the ProSun V3 Model 42V3 should assure that it is used in
such an environment.
Immunity Test IEC 60601 Test Level Compliance Test Electromagnetic
Environment - Guidance
Electrostatic discharge
(ESD) IEC 61000-4-2
±2 kV, ±4 kV & ± 8 kV for
Contact Discharge
±2 kV, ±4 kV, ±8 kV and±
15kV for Air Discharge
±2 kV, ±4 kV & ± 8 kV for
Contact Discharge
±2 kV, ±4 kV, ±8 kV and±
15kV for Air Discharge
Floors should be wood,
concrete or ceramic tile.
Ifoorsarecoveredwith
synthetic material, the
relative humidity should be
at least 30%.
Electrical fast transient/
burst IEC 61000-4-4
±2kV for power supply lines
±1kV for input/output lines
±2kV for power supply lines
±1kV for input/output lines
Mains power quality
should be that of a typical
commercial or hospital
environment.
Surge IEC 61000-4-5 AC Mains Line to Ground
±0.5kV, ±1kV and ±2kV
AC Mains Line to Line
±0.5kV and ±1kV
AC Mains Line to Ground
±0.5kV, ±1kV and ±2kV
AC Mains Line to Line
±0.5kV and ±1kV
Mains power quality
should be that of a typical
commercial or hospital
environment.
Voltage dips, short
interruptions and voltage
variations on power supply
input lines
IEC 61000-4-11
<5% UT (100% dip in UT)
for 0.5 cycles
0% UT (100% dip in UT) for
1 cycle
70% UT (30% dip in UT) for
25/30 cycles
<5% UT (100% dip in UT)
for 250/300 cycles
<5% UT (100% dip in UT)
for 0.5 cycles
0% UT (100% dip in UT) for
1 cycle
70% UT (30% dip in UT) for
25/30 cycles
<5% UT (100% dip in UT)
for 250/300 cycles
Mains power quality
should be that of a typical
commercial or hospital
environment. If the user
of the ProSun V3 Model
42V3 requires continued
operation during power
mains interruptions, it is
recommended that the
ProSun V3 Model 42V3
be powered from an
uninterrupted power supply
or a battery.
Power frequency
(50/60Hz) magnetic
eld
IEC 61000-4-8
30 A/m 30 A/m Power frequency
magneticelds
should be at levels
characteristic of a
typical location in a
typical commercial or
hospital environment.
NOTE: UT is the a.c mains voltage prior to application of the test level.
