Chapter 2 Hardware Configuration
Page: 2-2
Prox-1635LF USER
′
S MANUAL
2-1. JUMPER & CONNECTOR QUICK REFERENCE TABLE
COM Connector .................................................… COM1, COM2
RS232/422/485 (COM2) Selection ........................ JP3
Keyboard or PS/2 Mouse Connector ……………. DIN1
Keyboard or PS/2 Mouse Selection ……………... JP4
External Keyboard Connector …………………… EXKB1
Reset Connector ..................................................... JP8 (1,2)
ATX Power Button ……………….…………...… JP11 (5,7)
AT/ATX Function Selection ……………………..
…………………….
JP8 (3,4), JP13,
JP9
Hard Disk Drive LED Connector .......................... JP11 (2,4,6,8)
EXTSMI Connector …………………………… JP11 (1,3)
VGA Connector ………......................................... VGA1
Floppy Disk Drive Connector ................................ FDD1
Hard Disk Drive Connector ................................... IDE1
Printer Connector ................................................... LPT1
CPU Fan Connector ............................................... FAN2
ATX Signal Connector ………………………….. JP10
Wake-On-LAN Connector ………………………. WOL1
Universal Serial Bus Connector ............................. JP5, JP6
NMI/Reset/Clear Watchdog …………………..…. JP8
LAN Connector ..................................................... UTP1
Power Connector ………………………………… PW1
IrDA Connector …………………………………. IRDA1
Clear CMOS Data Selection …………..……..….. JP1
Memory Installation ...............................................
DIMM1
INTB/SERIRQ Selection ……………………….. JP7
PPCI Connector ……………….………………… PPCI
CPU Speed Selection ……………………………. JP2
LCD Connector ………………………………….. LCD1
Inverter Connector ………………………………. JP15
Power LED Connector ………………………….. PW_LED1
