Chapter 2 Hardware
Co
nfiguration
Page: 2-8
Prox-1635LF USER
′
S MANUAL
2-5. RS232/422/485 (COM2) SELECTION
JP3 :
RS-232/422/485 Sel
ection
COM2 is select
able for RS-232, 422, 485 functi
on.
The jumper settings are as follows :
COM 2
Function
Jumper Setting
(pin closed)
Jumper
Illustration
RS-232
Open
RS-422
1-2, 5-6, 7-
8, 9-10
11-12,13-14,15-
16
17-18, 19-20
RS-485
1-3, 4-6, 7-
8, 9-10
11-12,13-14,15-
16
17-18, 19-20
*** Manufactory default
--- RS-232.
