Chapter 2 Hardware Configuration
Prox-1635LF USER
′
S MANUAL
Page: 2-13
2-14. VGA CONNECTOR
VGA1 : VGA Connector
The pin assignments are as follows:
PIN ASSIGNMENT
1 RED
2 GREEN
3 BLUE
4 NC
5 GND
6 GND
7 GND
8 GND
9 VCC
10 GND
11 NC
12 SPD1
13 HSYNC
14 VSYNC
15 SPCLK1
