Chapter 4 Award BIOS Setup
Prox-1635LF USER
′
S MANUAL
Page: 4-17
4-6. INTEGRATED PERIPHERALS
Choose〝INTEGRATED PERIPHERALS〞from the main setup menu, a
display will be shown on screen as below:
Phoenix – Award CMOS Setup Utility
Integrated Peripherals
▶
VIA OnChip IDE Device
▶VIA OnChip PCI Device
▶SuperIO Device
[Press Enter]
[Press Enter]
[Press Enter]
Item Help
Init Display First
[PCI Slot]
Menu Level
►
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Integrated Peripherals Setup Screen
By moving the cursor to the desired selection and by pressing the <F1> key,
the all options for the desired selection will be displayed for choice.
In bios setup menu item if support USB device boot, it will cause that Win9x
detects the same storage twice when reboot the system, then USB HDD will
fail.
Note: this cause only happen under Win9x, the phenomenon is a limitation.
