Chapter 4 Award BIOS Setup
Page: 4-20
Prox-1635LF USER
′
S MANUAL
SUPER IO DEVICE:
The options for these items are found in its sub menu. By pressing the
<ENTER> key, you are prompt to enter the sub menu of the detailed options
as shown below:
Phoenix – Award CMOS Setup Utility
SuperIO Device
Item Help
Onboard FDC Controller
Onboard Serial Port 1
Onboard Serial Port 2
UART Mode Select
X UART Duplex Mode
Onboard Parallel Port
Parallel Port Mode
X ECP Mode Use DMA
[Enabled]
[3F8/IRQ4]
[2F8/IRQ3]
[Normal]
Half
[378/IRQ7]
[SPP]
3
Menu Level ►
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Descriptions on each item above are as follows:
1. Onboard FDC Controller
Select Enabled if the system has a floppy disk controller (FDC) installed
on the system board and you wish to use it. If you install and-in FDC or
the system has no floppy drive, select Disabled.
2. Onboard Serial Port 1/2
Select an address and corresponding interrupt for the first and second
serial ports.
3. UART Mode Select
This item allows you to select UART mode.
4. UR2 Duplex Mode
This item allows you to select the IR half/full duplex function.
5. Onboard Parallel Port
This item allows you to determine access onboard parallel port
controller with which I/O address.
6. Parallel Port Mode
Select an operating mode for the onboard parallel (printer) port.
Select Normal, Compatible, or SPP unless you are certain your
hardware and software both support one of the other available modes.
7. ECP Mode Use DMA
Select a DMA channel for the parallel port for use during ECP mode.
To Next Page
