Chapter 4: Configuration
About
Psion Omnii Hand-Held Computer User Manual
62
Printer Port allows you to assign and enable a virtual outgoing COM port selected from the drop-down
menu to communicate with a paired Bluetooth printer. Keep in mind that when a port is chosen, the printer
must be on and connected to the chosen port for a remote device to be able to connect.
• Select a port within the Printer Port drop-down list, e.g. BSP1:
• Check the Printer Port check box.
•Open the Device tab and tap on Scan.
• Tap-and-hold each Bluetooth Printer device entry and then select Pair, key-in the Passcode (if needed)
and then tap Done. DO NOT select any services!
•Close the Bluetooth Manager.
• Select the Bluetooth device to print to—you will need to key-in (or programmatically raise) the following
key sequence [CTRL] [ALT] [F1].
• You can now select the Bluetooth device to which you wish to print.
Allow Bluetooth to wake system allows remote Bluetooth devices to wake the Omnii by requesting a Blue-
tooth service that requires host intervention. This feature can also be used when the Omnii is waking from
suspend to significantly to reduce the initialization time of the Bluetooth system.
4.4.5 About
Device Name displays the broadcasted name of the hand-held. The name can be changed in the System
Properties applet: Start>Settings>Control Panel>System icon>Device Name tab.
Local Address displays the MAC address (BD_Addr) of the Bluetooth chip.
HCI Version & LMP Version display the version of the chip firmware.
Component indicates the version of the Psion Bluetooth Subsystem (the manager, drivers, etc).
Profiles lists the supported profiles on this specific Omnii.
4.4.6 The Bluetooth GPRS WAN Connection
The following steps describe how to set up an Internet data connection using a GSM cellular telephone with
Bluetooth. The Omnii communicates via Bluetooth to the cell phone, which then accesses a WAN (Wide Area
Network) and transfers data using GPRS.
1. Enable the Dial-Up Networking service in the cell phone.
2. Make the phone discoverable.
3. Pair the phone service with the Omnii Dial-Up Networking service using the Bluetooth Manager.
(For instructions on pairing devices, refer to “Pairing a Device” on page 59.)
4. To set up the Internet parameters, choose the Network And Dial-up Connections icon from the
Control Panel.
